Description
TECHNICAL SPECIFICATIONS
| General Info |
|---|
| Model | Abound Ebike |
| Pedal Assist | 4 Levels |
| Range | Up to 50 miles |
| Total Weight Limit | 440 lbs |
| Ideal Use | Cargo & Utility |
| Folding | No |
| Rider Height | 4’11” – 6’3″ |
| Weight | 82 lbs |
| Safety Certified | TUV Rheinland Certified in accordance with UL 2849 |
| Frameset |
|---|
| Frame | Double-Butted Aluminum Alloy |
| Fork | Suspension Fork with 50mm travel, with lockout |
| Footboards | Aluminum |
| Frame Style | Step-Through |
| Wheelset |
|---|
| Rim | Double Wall Aluminum 36h Front & Rear |
| Tubes | Butyl Rubber, Schrader Valve |
| Hubs | 36H Disc Nutted Front, Nutted Rear |
| Tires | 20 x 2.4 |
| Spokes | Black Stainless 13G Front / Iron 12G Rear |
| Ebike System |
|---|
| Motor | 750w (sustained), 48v Rear Hub |
| Throttle | Aventon LH Handlebar Mounted |
| Display | LCD Smart “Easy Read” |
| Sensors | Double Sided Bottom Bracket Torque Sensor |
| Charger | 48V, 3 Amp Fast Charger |
| Lights | Front and rear lights integrated |
| Battery | Samsung 2100 cells, 48V, 14.4AH, 678.2Wh, UL UN38.3 MSDS certification |
| Speed | Class 2 |
| Drivetrain |
|---|
| Pedals | 9/16″ Alloy Platform |
| Bottom Bracket | Square Taper, Sealed, Torque Sensor |
| Crankset | 170mm w/ 52 T |
| Rear Derailleur | Shimano 7 speed |
| Cassette | 14-28T, 7 Speed |
| Shift Lever | 7 Speed Twist |
| Chain | 148 Link, 7 Speed |
| Cockpit |
|---|
| Saddle | Aventon Saddle |
| Seatpost | Dropper Seatpost, 30.9mm x 440mm |
| Stem | Folding, Height Adjustable, 31.8mm, 9 Degree Rise |
| Seat Clamp | 34.9mm Quick Release |
| Handlebars | Aluminum 31.8mm, 700mm |
| Headset | Sealed Bearing Headset |
| Grips | Ergonomic Comfort |
| Included Accessories |
|---|
| Kickstand | Included, center mount |
| Storage Bag | Polyester, EVA Waterproof |
| Rear Rack Weight Limit | 143 lbs |
| Fenders | Included |
| Rear Rack | Included |
| Miscellaneous |
|---|
| Dimensions | Bike Box: 167cm x 37cm x 73cm |
| Suspension | Front |
Technical Overview
The Abound ships as a Class II ebike, with pedal assist and throttle. The Abound will also operate with the throttle unplugged and removed, should you want to ride in an area where throttles are prohibited. Aventon ebikes are built to the IPX4 water-resistant standard. IPX4 means that your bike is resistant to water splashes from any direction. This means it’s OK to ride your ebike in light rain. It won’t be harmed by spray from a wet road or raindrops. Your ebike is not intended to be exposed to prolonged rain, be submerged, or subjected to a pressurized spray. Don’t use a pressure washer or sprayer to clean your ebike.
*Max range determined using PAS 1 throughout flat terrain with a rider weight of 160 lb.
