Description
| Electric Bike Specifications | |
|---|---|
| Component | Details |
| Battery | 14Ah 672 Wh semi-integrated battery Bikes shipped to NYC are compliant with UL 2849 and 2271. |
| Charger | 48V, 2 Amp Rad Power Bikes smart charger, operates on 100V-240V AC power outlets |
| Display | LCD display. See Display section below for details. |
| Hub Motor | Rear hub 750W Stated wattage is the manufacturer’s rated power capacity. Actual power-to-ground wattage is under 750W to ensure ebike regulatory compliance and may vary depending on riding conditions. |
| Lights | Auto-on feature Front: LED headlight Rear: Integrated taillight with brake light and flash mode |
| Pedal Assist | Pedal cadence sensor, 4 PAS levels, plus a zero assist option |
| Range | Estimated 25-45+ miles per charge |
| Throttle | Half twist grip |
| USB Ports | No port |
| To ensure uninterrupted shipping, some parts may differ from those listed. Rest assured, our engineers rigorously test each component to guarantee quality and compatibility. | |
| Bike Components | |
|---|---|
| Component | Details |
| Bell | Yes |
| Brake System | Tektro mechanical disc (MD-M300) |
| Brake Pads | Semi-Metallic compound (Tektro P20.11) |
| Brake Rotors | Tektro 180 mm |
| Crank Set | 53T with dual-sided chain ring guard, 170 mm crank arms |
| Derailleur | n/a |
| Fenders | Available for purchase separately |
| Fork | Rigid steel fork |
| Frame | Aluminum |
| Freewheel/Cassette | 16 tooth freewheel |
| Gearing | Single speed |
| Grips | Ergonomic rubber comfort grips |
| Handlebar | Aluminum, 686 mm wide |
| Kickstand | Dual leg, spring loaded, steel |
| Pedals | Composite platform, CrMo axle with reflectors, standard 9/16″ x 20 TPI threading |
| Rear Rack | Integrated, 120 lb carrying capacity |
| Saddle | Moped-style saddle with extra padding |
| Seatpost | 390 mm x 27.2 mm |
| Seatpost Clamp | Quick release |
| Shifter | N/A |
| Stem | 50 mm + 30º (15 mm rise) |
| Tires | Kenda K-Rad 20″ x 3.3″, 4-ply with K-Shield puncture-resistant liner *tires received may not include branding |
| To ensure uninterrupted shipping, some parts may differ from those listed. Rest assured, our engineers rigorously test each component to guarantee quality and compatibility. | |
Geometry
- Rider Heights: 4’11” – 6’2″ (with approx. inseam between 26.75″-37″. See sizing section below.)
- Bike Weight: 65 lb, 57.3 with battery removed
- Payload: 300 lb
- Rear Rack Payload: 120 lb
- Handlebar Height: 42-45″
- Reach: 15″
- Seat Height: From ground: 31.5″ – 42.5″
From pedal bottom stroke: 25.75″ – 37″ - Standover Height: 16.5″
- Total Length: 68″
- Wheelbase: 45″
- Seat Tube Length: 18″
