Description
| Electric Bike Electronics | |
|---|---|
| Battery | 14Ah 672 Wh external battery Bikes shipped to NYC are compliant with UL 2849 and 2271. |
| Charger | 48V, 2 Amp Rad Power Bikes smart charger, operates on 100V-240V AC power outlets |
| Class | Class 2 |
| Display | Backlit LCD. See Display section below for details. |
| Hub Motor | Rear hub 750W Stated wattage is the manufacturer’s rated power capacity. Actual power-to-ground wattage is under 750W to ensure ebike regulatory compliance and may vary depending on riding conditions. |
| Lights | Auto-on feature Front: LED headlight Rear: Integrated taillight with brake light and flash mode |
| Pedal Assist | Pedal cadence sensor, 5 PAS levels, plus a zero assist option |
| Range | Estimated 25-45+ miles |
| Throttle | Half twist throttle |
| USB Ports | One port |
| To ensure uninterrupted shipping, some parts may differ from those listed. Rest assured, our engineers rigorously test each component to guarantee quality and compatibility. | |
| Electric Bike Components | |
|---|---|
| Bell | Yes |
| Brake System | Tektro Aries Mechanical Disc MD-M300 |
| Brake Pads | Metallic |
| Brake Rotors | 180 mm |
| Crank Set | 48T with dual-sided aluminum bashguard, 170 mm crank arms |
| Derailleur | 7-speed Shimano |
| Fenders | Full coverage front and rear fenders |
| Fork | RST spring fork, 80 mm travel, with lockout and preload adjustment |
| Frame | Aluminum |
| Freewheel/Cassette | 7-speed freewheel, 11-34T |
| Gearing | 1 x 7-speed |
| Grips | Ergonomic imitation leather grips |
| Handlebar | Aluminum, 686 mm wide |
| Kickstand | Side-mounted, adjustable lean angle |
| Pedals | Forged aluminum platform, CrMO axle with reflectors, standard 9/16″ x 20 TPI threading |
| Rear Rack | Integrated, 120 lb carrying capacity |
| Saddle | Custom Rad Power Bikes moped-style |
| Seatpost | 390 mm x 27.2 mm |
| Seatpost Clamp | Quick release |
| Shifter | Shimano, 7-speed thumb shifter |
| Stem | 50 mm + 30º (15 mm rise) |
| Tires | Kenda K-Rad 20″ x 3.3″ *tires received may not include branding |
| To ensure uninterrupted shipping, some parts may differ from those listed. Rest assured, our engineers rigorously test each component to guarantee quality and compatibility. | |
Geometry
- Rider Heights: 4’11” – 6’2″ (Approx. bike inseam between 26″ and 36.25″)
- Bike Weight: Total: 77 lb, 69.3 lb with battery removed
- Payload: 300 lb
- Rear Rack Payload: 120 lb
- Handlebar Height: 45.75″ – 47.25″ (116 – 120 cm)
- Reach: 15.5″ (39.4 cm)
- Seat Height: From ground: 30.5″ – 41″ (From pedal bottom stroke: 26″ – 37.5″)
- Standover Height: 16.5″ (42 cm)
- Total Length: 71.5″ (182 cm)
- Wheelbase: 46.5″ (118 cm)
- Seat Tube Length: 18″ (46 cm)
